1/2.8" CMOS, 1920 × 1080 @ 30FPS
Sensitivity: 0.002 Lux/F1.6, 30 IRE, 0 Lux IR on
Fixed lens 2.8mm (107°)
True Day / Night with ICR Filter, Visible white LED up to 60 m
BLC / HLC / True WDR 130 dB, 3D DNR
Built-in microphone
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Eyeball design, metal core, IP67, outdoor/indoor use, -40°C~+60°C
Power 12 VDC, 5.1 W max
| Techninė specifikacija |
| Camera design |
Eyeball |
| Effective pixels |
1920(H)×1080(V) |
| Electronic Shutter Speed |
PAL: 1/25s–1/100000s NTSC: 1/30s–1/100000s |
| Environment |
Outdoor |
| Focal length |
2.8mm |
| Full Description Line |
Type Fixed Dome/HDTV/Megapixel/Outdoor|Sensor size 1/2.8" CMOS|Focal Length 2.8mm|Lens Mount M12|Min. Illumination 0.02 Lux|Effective pixels 1920(H)×1080(V)|Electronic Shutter Speed PAL: 1/25s–1/100000s NTSC: 1/30s–1/100000s|Microphone Built-in|Power supply requirements 12V ±30% DC |
| IR Illumination |
Yes |
| Lens Mount |
M12 |
| Microphone |
Built-in |
| Min. Illumination |
0.02 |
| Pixel Resolution |
2 |
| Power consumption |
5.1 |
| Power supply requirements |
12V ±30% DC |
| Sensor size |
1/2.8" CMOS |
| Shipping Box Depth |
15 |
| Shipping Box Height |
13.5 |
| Shipping Box Weight |
0.62 |
| Shipping Box Width |
14 |
| Shipping box quantity |
1 |
| Unit Brutto Volume |
0.002835 |
| Unit Gross Weight |
0.62 |
| Unit Net Weight |
0.17 |
| Vendor Homepage |
www.dahuasecurity.com/products/All-Products/HDCVI-Cameras/Lite-Series/1080P/1080-P/HAC-HDW1200TRQ(-A) |
| iOS |
12V |
