Pentabrid capability: Each channel supports up to 6MP: IP, HDCVI, AHD, TVI and CVBS access can be configured
16-channel BNC interface
Recording: HDCVI/AHD/HD-TVI recording:, 5MP, 4MP, 3MP, 2MP
All channel 5M-N (1 fps–10 fps); 4M-N/1080P (1 fps–15fps); 1080N/720P/960H/D1/CIF (1fps–25/30 fps)
IP: 16+8 channels, each channel up to 6MP, Max 128 Mbps incoming bandwidth
AI Coding/H.265+/H.265/H.264+/H.264 video compression
G.711A, G.711U, PCM audio compression,
1x SATA interface up to 16 TB storage
VGA/HDMI up to 4K output
RJ-45, 2x USB ports, RS485
No front panel control, 1/1 Audio I/O, no Alarm I/O, Audio over Coax for 8 channels
Mini 1U case, mouse included
ONVIF 16.12, CGI Conformant, Smart Search
Third-party IP camera support: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
AI: Up to 2 channels video stream (analog channel) Perimeter Protection
Up to 16 channels video stream (analog channel) SMD Plus
Up to 2 channels video stream (analog channel) human face recognition
IoT & POS functionalities
Free IP monitoring software available
| Techninė specifikacija |
| 15pin D-sub |
1 |
| Audio-In |
1 |
| Audio-Out |
1 |
| Camera Compatibility |
AHD 5MP/Analog/HDCVI 1080P/HDCVI 4MP/HDCVI 720P/HDCVI 8MP/HD-TVI/TurboHD 5MP/IP |
| DVR type |
8 Channel |
| Dimensions |
260.0 mm × 237.4 mm × 47.6 mm |
| Full Description Line |
8 Channel|Camera Compatibility Analog/IP/AHD 5MP/HDCVI 720P/HDCVI 1080P/HDCVI 4MP/HDCVI 8MP/HD-TVI/TurboHD 5MP|SATA|USB|1x15pin D-sub|1xHDMI|1xAudio-In|1xAudio-Out|DC12V, 2A |
| HDMI |
1 |
| Power supply requirements |
DC12V, 2A |
| SATA |
Yes/Yes |
| Shipping Box Depth |
33.5 |
| Shipping Box Height |
31.5 |
| Shipping Box Weight |
1.54 |
| Shipping Box Width |
9 |
| Shipping box quantity |
1 |
| USB |
Yes/Yes |
| Unit Brutto Volume |
0.00901 |
| Unit Gross Weight |
1.51 |
| Unit Net Weight |
0.9 |
| Vendor Homepage |
www.dahuasecurity.com/ceen/products/All-Products/HDCVI-Recorders/Lite-AI-Series/I3-Series/4K-N/5MP-Series/XVR5108HS-4KL-I3 |
