- 1/2.7”5Megapixel progressive CMOS, 2960 × 1668 @ 20FPS
- Minimum illumination: 0.005 lux @ F1.5 (Color, 30 IRE), 0.0005 lux @ F1.5 (B/W, 30 IRE), 0 lux (Illuminator on)
- True Day/Night (ICR), BLC / HLC / True WDR 120dB /3D DNR
- Motorized vari-focal 2.7 mm-13.5 mm fixed lens (99°-28°)
- Up to 60 meters Smart IR Illumination
- H.265; H.264; H.264H; H.264B; MJPEG encoding, ONVIF(Profile S/Profile G);CGI;P2P;Milestone;Genetec
- 1/1 Audio I/O, G.711a; G.711Mu; PCM; G.726; G.723 encoding
- 1/1 Alarm I/O
- Micro SD card up to 256GB supported
- Metal case, IP67, IK10, -30°C~+60°C, PoE / 12VDC power, 7.3W max
- Smart capabilities: Tripwire; intrusion (Recognition of human and vehicle). Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
- Free IP monitoring software available
| Techninė specifikacija |
| Alarm In |
1 |
| Alarm Out |
1 |
| Audio-In |
1 |
| Audio-Out |
1 |
| Camera design |
Bullet |
| Colour |
White |
| Dimensions |
244.1 x 79.0 x 75.9 mm |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100000 s |
| Environment |
Outdoor |
| Focal length |
2.7 mm-13.5 mm |
| Full Description Line |
Type HDTV/Megapixel/Outdoor|Pixel Resolution 5 Mega Pixel|Focal Length 2.7 mm-13.5 mm|IR Illumination|Sensor size 1/2.7”|Lens Mount M14|Min. Illumination 0.005 Lux|Electronic Shutter Speed Auto/Manual 1/3 s–1/100000 s|1xAudio-In|1xAudio-Out|1xMicroSD Card Slot|1xRJ45|1xAlarm In|1xAlarm Out|Supports card capacities up to 256GB|Power options PoE/12V|Power supply requirements 12 VDC|Environment Outdoor|Operating temperature range -30°C~+60°C|Colour White|Dimensions 244.1 x 79.0 x 75.9 mm |
| IR Illumination |
Yes |
| Lens Mount |
M14 |
| MicroSD Card Slot |
1 |
| Min. Illumination |
0.005 |
| Operating temperature range |
-30°C~+60°C |
| Pixel Resolution |
5 |
| Power consumption |
7.3 |
| Power supply requirements |
12 VDC |
| RJ45 |
1 |
| Sensor size |
1/2.7” |
| Shipping Box Depth |
31 |
| Shipping Box Height |
14.5 |
| Shipping Box Weight |
1.16 |
| Shipping Box Width |
15.5 |
| Shipping box quantity |
1 |
| Supports card capacities up to |
256GB |
| Unit Brutto Volume |
0.0069673 |
| Unit Gross Weight |
1.16 |
| Unit Net Weight |
0.82 |
| Vendor Homepage |
www.dahuasecurity.com/products/All-Products/Network-Cameras/WizSense-Series/3-Series/5MP/IPC-HFW3541T-ZAS-S2 |
| iOS |
12V/PoE |
