1/2.8”2 x 4 Megapixel progressive CMOS, 4096 × 1800
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Sensitivity: 0.0005 lux @ F1.0, 0.0002 lux @ F1.0 (B/W,30 IRE), 0 Lux (Illuminator on)
Fixed focus lens 3.6 mm (x 2), Field if view: 180°
Illumination Distance 40m, warm white LED
Video Frame Rate: 4096 × 1800 @ (1–25 fps)
BLC / HLC / True WDR 140dB / 3D DNR
1/1 Audio I/O, 1/1 Alarm I/O, Built-in MIC, Built-in Speaker
256 GB SD card supprt, ONVIF (Profile S/Profile G/Profile T); CGI; Milestone
Smart capabilities: Abandoned object; missing object, Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection, Tripwire people counting and people counting in area, generating and exporting report (day/month/year); queue management, generating and exporting report (day/month); 4 rules can be set for tripwire, people counting in area and queue management, Heat Map
Power: 12V DC 13.8W, PoE
Metal case, IP67, −40°C to +60°C
Wall bracket included
Known aliases: DH-IPC-PFW5849P-A180-E2-ASTE-0360B, IPC-PFW5849P-A180-E2-ASTE-0360B, DH-IPC-PFW5849-A180-E2-ASTE-0360B, IPC-PFW5849-A180-E2-ASTE-0360B, IPC-PFW5849P-A180-E2-ASTE
| Techninė specifikacija |
| Alarm In |
1 |
| Alarm Out |
1 |
| Audio-In |
1 |
| Audio-Out |
1 |
| Camera design |
Box |
| Dimensions |
298.3 mm × 172.5 mm × 120.5 mm |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Environment |
Outdoor |
| Focal length |
3.6mm |
| Full Description Line |
Type Fixed/Outdoor|Pixel Resolution 4 Mega Pixel|Focal Length 3.6mm|IR Illumination|Sensor size 1/2.8”4 × 2Megapixel progressive CMOS|Microphone Built-in|Lens Mount M12|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xAudio-In|1xAudio-Out|1xSD Card Slot|1xRJ45|1xAlarm In|1xAlarm Out|Supports card capacities up to 256GB|Power options PoE/12V|Power supply requirements 12V DC 13.8W, PoE|Environment Outdoor|Operating temperature range −40°C to +60°C|Dimensions 298.3 mm × 172.5 mm × 120.5 mm |
| IR Illumination |
Yes |
| Lens Mount |
M12 |
| Microphone |
Built-in |
| Operating temperature range |
−40°C to +60°C |
| Pixel Resolution |
4 |
| Power supply requirements |
12V DC 13.8W, PoE |
| RJ45 |
1 |
| SD Card Slot |
1 |
| Sensor size |
1/2.8”4 × 2Megapixel progressive CMOS |
| Shipping Box Depth |
36.5 |
| Shipping Box Height |
18 |
| Shipping Box Weight |
1.84 |
| Shipping Box Width |
17.5 |
| Shipping box quantity |
1 |
| Supports card capacities up to |
256GB |
| Unit Brutto Volume |
0.0115 |
| Unit Gross Weight |
1.84 |
| Unit Net Weight |
1.42 |
| Vendor Homepage |
www.dahuasecurity.com/products/All-Products/Network-Cameras/WizMind-Series/Panoramic-Series/Multi-Sensor/IPC-PFW8840-A180 |
| iOS |
12V/PoE |
